Part no. 46.14.000.220
| Axle load single axle |
750kg |
| Suspension |
Square rubber suspension |
| Wheel bearing |
Tapered roller bearing |
| Centre hole rim |
min. 56.5mm |
Original operating instructions
Replacement part identification number (ETI) XX.14.000.XXX
SCOPE OF DELIVERY
Axle
Ball-head wheel bolts M12x1.5
DETAILS
- Speed up to 140 km/h
- Drawbar connection: Clamping shells see Accessories
- Wheel connections: 140x5 on demand
- Special axle mounts and drawbar connections on demand
- Also available with watertight bearings
- Axle body fully hop-dip galvanised: Permanent surface protection
- Independent wheel suspension: Optimum compensation of uneven road surfaces
- Maintenance-free suspension: Lower maintenance costs
- Sturdy axle construction: Suitable for extreme loads such as off-road or construction sites
- Tapered roller bearing
