Home / Overrun device V type ZAF 2,0-3, 1250 to 2000kg, 48.36.581.102
connection 166mm, dimension A 312mm, H 37,5mm, L 660mm, FH 167-210mm, FV 110mm, S 13mm, nose load 150kg, drawbar installation version top and bottom, can be combined with BPW wheel brake S1704-7 / S2005-7 / S2504-7, with coupling head ZKAS 3,0-1. Read more...
Part no. OLD 48.36.581.102 (48.29.581.021)
Part no. NEW 4014349
| Permitted gross weight (kg) | 1250-2000 |
| Sales designation (type) | ZAF 2.0-3 |
| A |
312mm |
| H | 37,5mm |
| L |
660mm |
| FH | 167-210mm |
| FH2 |
- |
| FV | 110mm |
| S |
13mm |
| Perm. nose load (kg) |
150 |
| Drawbar installation version | top + bottom |
| Combined wheel brakes (RASK) | S1704-7 and S2005-7 and S2504-7 |
| ECE test code |
E1 55R-012318 |
