connection 166mm, nose load 100kg, drawbar installation version top, combined with BPW wheel brake S1704-7, S2005-7 and S2504-7 RASK, with coupling head WW220R-B. Read more...

Wishlist: Add to comparison:
Permitted gross weight (kg) 800 - 1600
Sales designation (type) ZAF 1.6-3
Order No. 4014317
Reference No. 48.29.581.075
A
287mm
H 38,5mm
L
635mm
FH 167-217mm
FH2
-
FV 120mm
S
13mm
Perm. nose load (kg)
100
Drawbar installation version top
Combined wheel brakes (RASK) S1704-7, S2005-7 and S2504-7
ECE test code
E1 55R-01 2051
Replacement part identification number (ETI) NEW 827003
Replacement part identification number (ETI) OLD 48.29.58X.XXX



Original operating instructions
