connection 167mm, nose load 160kg, drawbar installation version top + bottom, combined with AL-KO wheel brake 2361, without hitch components. Read more...
Order no. | 1731695 |
Type | EH14 |
Total weight in kg | 700-1400 |
Imposed load in kg | 160 |
Drawbar installation version |
top / bottom |
Change-over relay lever? | no |
Can be combined with wheel brake |
2361 |
For jockey wheel |
48mm |
Hitch mounted | no |
ECE test report no. | Overrun device: R13: CD97/002 |
ECE type approval no. | Drawbar installation: E1 55R-01 10349 |
Here, you can find the catalogue page as a convenient PDF download.
You can also enter the part no. from the catalogue as a search term in our online store.
