drawbar ⌀70mm round, holes (screw connection) vertical 12.5mm, hole distance 90/116mm, perm. gross weight 750kg, nose load 75kg, material: steel. Read more...
| Drawbar ⌀ |
70mm |
| Holes (screw connection) | vertical 12.5mm |
| Hole distance | 90/116mm |
| Perm. gross weight | 750 kg |
| Nose load |
75 kg |
| D / Dc value |
7,19 kN |
| Material | steel |
| Tightening torque |
75 Nm |
| ECE type approval no. | E1 55R-01 0164 |
