consisting of brake shoes, pressure springs, tension springs, cover plates, casting number brake shoes 563267 and 563268, for one axle (2 wheel brakes left + right).
for AL-KO axles trailing arm and semi-trailing arm, single axle up to 900kg, tandem axle up to 1600kg, colour green, with articulation connection eyes and fixing bolts.
wheel load per hub up to max. 140 km/h 375kg, up to max. 40 km/h 450kg, wheel connection (G) 112x5, thread M12x1.5, offset 27-45, dimension A 203.5mm, dimension B 83.5mm, dimension C 39.5mm, bearing type Compact.
connection 130mm, nose load 75kg, drawbar installation version top, can be combined with AL-KO wheel brake 1637 / 2051, with coupling head AK 161, Soft-Dock.
rim size 6.00x14, hole number 6, rim centre hole Ø 161mm, bolt circle 205mm, offset -5, colour silver RAL9006, A2, load capacity 2430/1250kg at 30/140km/h.
rim size 5.50x14, hole number 4, rim centre hole Ø 57mm, bolt circle 100mm, offset +30, colour silver RAL9006, C60 taper-head, load capacity 775kg at 140km/h.
rim size 4.50x13, hole number 5, rim centre hole Ø 66.5mm, bolt circle 112mm, offset +30, colour silver RAL9006, R12 ball-head, load capacity 710kg at 140km/h.
build design radial, tyre size 195/70 R 14, TL (tubeless), load index 96, speed index N, tread CR-966, specification Verstärkt, load capacity 710kg at 140km/h, inflation pressure 2.7 bar.
build design radial, tyre size 205 R 14, TL (tubeless), load index 109/107, speed index P, tread MAXMILER PRO, load capacity 1030kg at 150km/h, inflation pressure 4.5 bar.
