BPW Braked axle 1050kg SWING, axle type CB 1055 for braked trailers

Home / CHASSIS PARTS / CHASSIS PARTS BPW / AXLES / BRAKED AXLE 1050KG SWING, AXLE TYPE CB 1055

JUST ORIGINAL PARTS

LIFE-TIME SUPPORT

SALE

POSITIVE REVIEWS

BPW Braked axle 1050kg SWING, axle type CB 1055

DETAILS

  • Speed up to 140 km/h
  • Drawbar connection: Clamping shells see Accessories
  • Axle shock absorber see Accessories
  • Wheel connections: 98x4, 130x4, 120x5, 140x5 on demand
  • Special axle mounts and drawbar connections on demand
  • Also available with watertight bearings
  • Axle body fully hop-dip galvanised: Permanent surface protection
  • Independent wheel suspension: Optimum compensation of uneven road surfaces
  • Maintenance-free suspension: Lower maintenance costs
  • Sturdy axle construction: Suitable for extreme loads such as off-road or construction sites
  • Sturdy, maintenance-free spreadlever brakes with auto-reverse: Simple adjustment of the brake from outside the wheel, subsequent connection of the brake cables possible without removal of the brake drum
  • Compact bearings (standard in the automotive industry): Maintenance-free, long service life, protected against dirt and water, lubricated for life with special grease
  • Incl. shock absorber bracket

How do I find the right axle?

Here, you can find the catalogue page as a convenient PDF download.
You can also enter the part no. from the catalogue as a search term in our online store.

Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.701
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.701
BC: dimension AM 1050mm, OHF: dimension FL 1500mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 557,80 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.702
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.702
BC: dimension AM 1100mm, OHF: dimension FL 1550mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 490,90 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.703
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.703
BC: dimension AM 1150mm, OHF: dimension FL 1600mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 563,30 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.704
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.704
BC: dimension AM 1200mm, OHF: dimension FL 1650mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 497,90 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.705
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.705
BC: dimension AM 1250mm, OHF: dimension FL 1700mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 568,80 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.706
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.706
BC: dimension AM 1300mm, OHF: dimension FL 1750mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 504,90 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.707
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.707
BC: dimension AM 1350mm, OHF: dimension FL 1800mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 574,30 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.708
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.708
BC: dimension AM 1400mm, OHF: dimension FL 1850mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 512,90 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.709
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.709
BC: dimension AM 1450mm, OHF: dimension FL 1900mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 579,80 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.710
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.710
BC: dimension AM 1500mm, OHF: dimension FL 1950mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 519,90 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.711
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.711
BC: dimension AM 1550mm, OHF: dimension FL 2000mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 585,30 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.712
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.712
BC: dimension AM 1600mm, OHF: dimension FL 2050mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 527,90 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.713
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.713
BC: dimension AM 1650mm, OHF: dimension FL 2100mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 590,80 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.714
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.714
BC: dimension AM 1700mm, OHF: dimension FL 2150mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 533,90 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.715
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.715
BC: dimension AM 1750mm, OHF: dimension FL 2200mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 596,30 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.716
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.716
BC: dimension AM 1800mm, OHF: dimension FL 2250mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 541,90 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.717
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.717
BC: dimension AM 1850mm, OHF: dimension FL 2300mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 601,80 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.718
BPW Braked tandem front axle 1050kg SWING axle type CB 1055, 46.21.379.718
BC: dimension AM 1900mm, OHF: dimension FL 2350mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 546,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg SWING axle type CB 1055, 46.21.379.887, Humer
BPW Braked axle 1050kg SWING axle type CB 1055, 46.21.379.887, Humer
BC: dimension AM 1600mm, OHF: dimension FL 1970mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 0°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 559,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg SWING axle type CB 1055, 46.21.379.888, Humer
BPW Braked axle 1050kg SWING axle type CB 1055, 46.21.379.888, Humer
BC: dimension AM 1500mm, OHF: dimension FL 1870mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 0°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 625,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1350kg axle type CB 1355, 46.25.379.126
BPW Braked axle SWING 1350kg axle type CB 1355, 46.25.379.126
BC: dimension AM 1600mm, OHF: dimension FL 2050mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 655,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg SWING axle type CB 1055, 46.21.316.614
BPW Braked axle 1050kg SWING axle type CB 1055, 46.21.316.614
BC: dimension AM 1400mm, OHF: dimension FL 1850mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 574,30 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg SWING axle type CB 1055, 46.21.379.556
BPW Braked axle 1050kg SWING axle type CB 1055, 46.21.379.556
BC: dimension AM 1200mm, OHF: dimension FL 1650mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 1.285,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg SWING axle type CB 1055, 46.21.379.063 WM Meyer 2230447
BPW Braked axle 1050kg SWING axle type CB 1055, 46.21.379.063 WM Meyer 2230447
BC: dimension AM 1550mm, OHF: dimension FL 2000mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 900,00 EUR Incl. tax Excl. Shipping costs
