total length A 1397mm, drawbar length C 730mm, drawbar section 70x70x4mm, perm. nose load 100kg, with coupling head AK 161, for wheel brake 1637 / 2051.
total length A 1397mm, drawbar length C 730mm, drawbar section 70x70x4mm, perm. nose load 100kg, with DIN drawbar eye D40/F, for wheel brake 1637 / 2051.
total length A 1647mm, drawbar length C 980mm, drawbar section 70x70x4mm, perm. nose load 100kg, with coupling head AK 161, for wheel brake 1637 / 2051.
total length A 1647mm, drawbar length C 980mm, drawbar section 70x70x4mm, perm. nose load 100kg, with DIN drawbar eye D40/F, for wheel brake 1637 / 2051.
total length A 1807mm, drawbar length C 1140mm, drawbar section 70x70x4mm, perm. nose load 100kg, with coupling head AK 161, for wheel brake 1637 / 2051.
total length A 1807mm, drawbar length C 1140mm, drawbar section 70x70x4mm, perm. nose load 100kg, with DIN drawbar eye D40/F, for wheel brake 1637 / 2051.
total length A 1967mm, drawbar length C 1300mm, drawbar section 70x70x4mm, perm. nose load 100kg, with coupling head AK 161, for wheel brake 1637 / 2051.
total length A 1967mm, drawbar length C 1300mm, drawbar section 70x70x4mm, perm. nose load 100kg, with DIN drawbar eye D40/F, for wheel brake 1637 / 2051.
total length A 2127mm, drawbar length C 1460mm, drawbar section 70x70x4mm, perm. nose load 100kg, with coupling head AK 161, for wheel brake 1637 / 2051.
total length A 2127mm, drawbar length C 1460mm, drawbar section 70x70x4mm, perm. nose load 100kg, with DIN drawbar eye D40/F, for wheel brake 1637 / 2051.
total length A 2287mm, drawbar length C 1620mm, drawbar section 70x70x4mm, perm. nose load 100kg, with coupling head AK 161, for wheel brake 1637 / 2051.
total length A 2287mm, drawbar length C 1620mm, drawbar section 70x70x4mm, perm. nose load 100kg, with DIN drawbar eye D40/F, for wheel brake 1637 / 2051.
