AL-KO Braked axle 900 - 2000kg DELTA, axle type SI-N - These axles must only be installed in caravans!

Home / CHASSIS PARTS / CHASSIS PARTS AL-KO / AXLES / BRAKED AXLES & ACCESSORIES / BRAKED AXLE 900 - 2000KG DELTA, AXLE TYPE SI-N, AXLES FOR CARAVANS

JUST ORIGINAL PARTS

LIFE-TIME SUPPORT

SALE

POSITIVE REVIEWS

AL-KO SEMI-TRAILING ARM AXLES HAVE BEEN DEVELOPED AND APPROVED SPECIFICALLY FOR USE IN CARAVANS.
CARAVANS ARE ONLY OPERATED WITHIN THE NOMINAL LOAD RANGE, AND ARE VERY
DEMANDING IN TERMS OF DRIVING DYNAMICS DUE TO
THEIR DESIGN, PARTICULARLY AT HIGH SPEEDS.
THESE AXLES HAVE BEEN DEVELOPED AND APPROVED PRECISELY FOR THESE BOUNDARY CONDITIONS.
NO OTHER APPLICATION AREA IS PERMITTED.

Braked axle 1300kg EURO1 axle type B 1200-5 Adria Altea 432 PX
AL-KO Braked axle 1300kg EURO1 axle type B 1200-5 Adria Altea 432 PX
BC: dimension A 1550mm, OHF: dimension C 2048mm, wheel connection 112x5, wheel brake type 2051 vers. Aa, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.490,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type B 1200-5
AL-KO Braked axle 1300kg EURO1 axle type B 1200-5
BC: dimension A 1430mm, OHF: dimension C 1995mm, wheel connection 112x5, wheel brake type 2051A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.117,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO COMPACT axle type B 1200-5
AL-KO Braked axle 1300kg EURO COMPACT axle type B 1200-5
BC: dimension A 1405mm, OHF: dimension C 1830mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.350,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type B 1200-5, COMPASS Pentrara 510/4
AL-KO Braked axle 1300kg EURO1 axle type B 1200-5, COMPASS Pentrara 510/4
BC: dimension A 1425mm, OHF: dimension C 1900mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.309,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type B 1200-5 Bürstner
AL-KO Braked axle 1300kg EURO1 axle type B 1200-5 Bürstner
BC: dimension A 1370mm, OHF: dimension C 1925mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.550,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg Euro1 axle type B 1200-5
AL-KO Braked axle 1300kg Euro1 axle type B 1200-5
BC: dimension A 1575mm, OHF: dimension C 2090mm, wheel connection 112x5, wheel brake type 2051A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.450,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type B 1200-5, Bürstner
AL-KO Braked axle 1300kg EURO Plus axle type B 1200-5, Bürstner
BC: dimension A 1366mm, OHF: dimension C 1920mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 25°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.550,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type B 1200-5 Home Car Rally 462
AL-KO Braked axle 1300kg EURO1 axle type B 1200-5 Home Car Rally 462
BC: dimension A 1330mm, OHF: dimension C 1810mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.299,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type DELTA SIN 12 FENDT 450J Saphir
AL-KO Braked axle 1300kg EURO1 axle type DELTA SIN 12 FENDT 450J Saphir
BC: dimension A 1570mm, OHF: dimension C 2080mm, wheel connection 112x5, wheel brake type 2051 vers. Aa, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.490,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type DELTA SIN 12
AL-KO Braked axle 1300kg EURO Plus axle type DELTA SIN 12
BC: dimension A 1550mm, OHF: dimension C 2080mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm.
Price 1.395,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type DELTA SIN 12, DETHLEFFS New Line 465 T
AL-KO Braked axle 1300kg EURO Plus axle type DELTA SIN 12, DETHLEFFS New Line 465 T
BC: dimension A 1310mm, OHF: dimension C 1790mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.300,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type Delta SIN 12
AL-KO Braked axle 1300kg EURO1 axle type Delta SIN 12
BC: dimension A 1340mm, OHF: dimension C 1818mm, wheel connection 100x4, wheel brake type 2051 A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.390,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type DELTA SI-N 12-2, THRUN-EICKER
AL-KO Braked axle 1300kg EURO Plus axle type DELTA SI-N 12-2, THRUN-EICKER
BC: dimension A 1415mm, OHF: dimension C 1895mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.309,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type DELTA SI-N 12, KNAUS, 1324353
AL-KO Braked axle 1300kg EURO Plus axle type DELTA SI-N 12, KNAUS, 1324353
BC: dimension A 1430mm, OHF: dimension C 1910mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.349,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type DELTA SI-N 12, DETHLEFFS / TEC
AL-KO Braked axle 1300kg EURO Plus axle type DELTA SI-N 12, DETHLEFFS / TEC
BC: dimension A 1415mm, OHF: dimension C 1895mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.380,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type DELTA SIN 12, FENDT 530 A JOKER 495 A
AL-KO Braked axle 1300kg EURO1 axle type DELTA SIN 12, FENDT 530 A JOKER 495 A
BC: dimension A 1500mm, OHF: dimension C 1980mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 30mm, swing arm position 30°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.305,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type DELTA SIN 12, Tabbert
AL-KO Braked axle 1300kg EURO1 axle type DELTA SIN 12, Tabbert
BC: dimension A 1580mm, OHF: dimension C 2090mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.395,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type DELTA SIN 12, KNAUS AZUR 500 / 510
AL-KO Braked axle 1300kg EURO Plus axle type DELTA SIN 12, KNAUS AZUR 500 / 510
BC: dimension A 1550mm, OHF: dimension C 2060mm, wheel connection 100x4, wheel brake type 2051 A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.375,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type DELTA SIN 12, KNAUS AZUR 500
AL-KO Braked axle 1300kg EURO Plus axle type DELTA SIN 12, KNAUS AZUR 500
BC: dimension A 1430mm, OHF: dimension C 1940mm, wheel connection 100x4, wheel brake type 2051 A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.269,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type DELTA SI-N 12 KNAUS - Bailey Ranger caravan
AL-KO Braked axle 1300kg EURO Plus axle type DELTA SI-N 12 KNAUS - Bailey Ranger caravan
BC: dimension A 1570mm, OHF: dimension C 2080mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.395,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type DELTA SIN 12, Bürstner TK490
AL-KO Braked axle 1300kg EURO Plus axle type DELTA SIN 12, Bürstner TK490
BC: dimension A 1550mm, OHF: dimension C 2030mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.395,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type DELTA SIN 12 FENDT 450J Saphir with AAA (automatic adjustment of the brake pads)
AL-KO Braked axle 1300kg EURO1 axle type DELTA SIN 12 FENDT 450J Saphir with AAA (automatic adjustment of the brake pads)
BC: dimension A 1570mm, OHF: dimension C 2080mm, wheel connection 112x5, wheel brake type 2051 vers. Aa, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.535,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type DELTA SIN 12, ERIBA HYMER NOVA 491
AL-KO Braked axle 1300kg EURO1 axle type DELTA SIN 12, ERIBA HYMER NOVA 491
BC: dimension A 1490mm, OHF: dimension C 1970mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.395,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type DELTA SI-N 12, WILK 500 TD and WILK de Luxe 500 MT/TD
AL-KO Braked axle 1300kg EURO Plus axle type DELTA SI-N 12, WILK 500 TD and WILK de Luxe 500 MT/TD
BC: dimension A 1475mm, OHF: dimension C 1990mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.395,00 EUR Incl. tax Excl. Shipping costs
Page 4 of 14
