AL-KO Braked axle 900 - 2000kg DELTA, axle type SI-N - These axles must only be installed in caravans!

Home / CHASSIS PARTS / CHASSIS PARTS AL-KO / AXLES / BRAKED AXLES & ACCESSORIES / BRAKED AXLE 900 - 2000KG DELTA, AXLE TYPE SI-N, AXLES FOR CARAVANS

JUST ORIGINAL PARTS

LIFE-TIME SUPPORT

SALE

POSITIVE REVIEWS

AL-KO SEMI-TRAILING ARM AXLES HAVE BEEN DEVELOPED AND APPROVED SPECIFICALLY FOR USE IN CARAVANS.
CARAVANS ARE ONLY OPERATED WITHIN THE NOMINAL LOAD RANGE, AND ARE VERY
DEMANDING IN TERMS OF DRIVING DYNAMICS DUE TO
THEIR DESIGN, PARTICULARLY AT HIGH SPEEDS.
THESE AXLES HAVE BEEN DEVELOPED AND APPROVED PRECISELY FOR THESE BOUNDARY CONDITIONS.
NO OTHER APPLICATION AREA IS PERMITTED.

Braked axle 1000kg EURO1 axle type Delta SIN 10 WILK
AL-KO Braked axle 1000kg EURO1 axle type Delta SIN 10 WILK
BC: dimension A 1375mm, OHF: dimension C 1890mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 30mm, swing arm position 10°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.486,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1000kg EURO1 axle type Delta SI-N 10
AL-KO Braked axle 1000kg EURO1 axle type Delta SI-N 10
BC: dimension A 1335mm, OHF: dimension C 1870mm, wheel connection 100x4, wheel brake type 2051 A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.339,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1000kg EURO Plus axle type DELTA SIN 10, DETHLEFFS
AL-KO Braked axle 1000kg EURO Plus axle type DELTA SIN 10, DETHLEFFS
BC: dimension A 1310mm, OHF: dimension C 1790mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.339,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1000kg EURO PLUS axle type DELTA SIN 10, DETHLEFFS
AL-KO Braked axle 1000kg EURO PLUS axle type DELTA SIN 10, DETHLEFFS
BC: dimension A 1340mm, OHF: dimension C 1818mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.325,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1000kg EURO PLUS axle type DELTA SIN 10, DETHLEFFS
AL-KO Braked axle 1000kg EURO PLUS axle type DELTA SIN 10, DETHLEFFS
BC: dimension A 1383mm, OHF: dimension C 1908mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.330,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1000kg EURO1 axle type Delta SI-N 10 FENDT 620
AL-KO Braked axle 1000kg EURO1 axle type Delta SI-N 10 FENDT 620
BC: dimension A 1760mm, OHF: dimension C 2270mm, wheel connection 100x4, wheel brake type 2051 Aa, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.325,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1000kg EURO1 axle type DELTA SIN 10, DETHLEFFS
AL-KO Braked axle 1000kg EURO1 axle type DELTA SIN 10, DETHLEFFS
BC: dimension A 1790mm, OHF: dimension C 2270mm, wheel connection 100x4, wheel brake type 2051 vers. Aa, offset (ET) 30mm, swing arm position 16°, axle profile 97mm.
Price 1.315,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1000kg EURO1 axle type Delta SI-N 10 FENDT 700
AL-KO Braked axle 1000kg EURO1 axle type Delta SI-N 10 FENDT 700
BC: dimension A 1790mm, OHF: dimension C 2270mm, wheel connection 100x4, wheel brake type 2051 Aa, offset (ET) 30mm, swing arm position 16°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.390,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1100kg EURO axle type B 1000-5, Bürstner
AL-KO Braked axle 1100kg EURO axle type B 1000-5, Bürstner
BC: dimension A 1415mm, OHF: dimension C 1895mm, wheel connection 100x4, wheel brake type 2051, offset (ET) 27-33mm, swing arm position 25°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.350,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1100kg EURO1 axle type B 1000-5
AL-KO Braked axle 1100kg EURO1 axle type B 1000-5
BC: dimension A 1430mm, OHF: dimension C 1910mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 27-33mm, swing arm position 25°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.310,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1100kg EURO1 axle type B 1000-5, Adria
AL-KO Braked axle 1100kg EURO1 axle type B 1000-5, Adria
BC: dimension A 1556mm, OHF: dimension C 1980mm, wheel connection 112x5, wheel brake type 2051 A, offset (ET) 27-33mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.310,00 EUR Incl. tax Excl. Shipping costs
FTF Braked axle 1200kg axle type BT97012 , Sir Caravelair
AL-KO FTF Braked axle 1200kg axle type BT97012 , Sir Caravelair
BC: dimension A 1350mm, OHF: dimension C 1790mm, wheel connection 130x4, wheel brake type 2051 vers. A, offset (ET) 20mm, swing arm position 23°, axle profile 70x4mm, ball-head wheel bolts M14x1.5.
Price 1.310,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type B 1200-5
AL-KO Braked axle 1300kg EURO1 axle type B 1200-5
BC: dimension A 1140mm, OHF: dimension C 1600mm, wheel connection 139.7x4, wheel brake type 2051 vers. Aa, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.390,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO COMPACT axle type B 1200-5
AL-KO Braked axle 1300kg EURO COMPACT axle type B 1200-5
BC: dimension A 1310mm, OHF: dimension C 1760mm, wheel connection 112x5, wheel brake type 2051A, offset (ET) 26-30mm, swing arm position 5°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.117,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO PLUS axle type B 1200-5
AL-KO Braked axle 1300kg EURO PLUS axle type B 1200-5
BC: dimension A 1415mm, OHF: dimension C 1895mm, wheel connection 112x5, wheel brake type 2051A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.390,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO COMPACT axle type B 1200-5 Caravalair Ambiance 410
AL-KO Braked axle 1300kg EURO COMPACT axle type B 1200-5 Caravalair Ambiance 410
BC: dimension A 1350mm, OHF: dimension C 1810mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.325,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO PLUS axle type B 1200-5
AL-KO Braked axle 1300kg EURO PLUS axle type B 1200-5
BC: dimension A 1460mm, OHF: dimension C 1941mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.309,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type B 1200-5
AL-KO Braked axle 1300kg EURO Plus axle type B 1200-5
BC: dimension A 1430mm, OHF: dimension C 1910mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 30mm, swing arm position 25°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.350,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO Plus axle type B 1200-5, ADRIA 5206
AL-KO Braked axle 1300kg EURO Plus axle type B 1200-5, ADRIA 5206
BC: dimension A 1480mm, OHF: dimension C 1964mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.395,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type B 1200-5 Bürstner
AL-KO Braked axle 1300kg EURO1 axle type B 1200-5 Bürstner
BC: dimension A 1565mm, OHF: dimension C 2045mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.597,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type B 1200-5
AL-KO Braked axle 1300kg EURO1 axle type B 1200-5
BC: dimension A 1320mm, OHF: dimension C 1846mm, wheel connection 100x4, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.309,90 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type B 1200-5, Bürstner
AL-KO Braked axle 1300kg EURO1 axle type B 1200-5, Bürstner
BC: dimension A 1430mm, OHF: dimension C 1910mm, wheel connection 112x5, wheel brake type 2051A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.310,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO COMPACT axle type B 1200-5, Trigano
AL-KO Braked axle 1300kg EURO COMPACT axle type B 1200-5, Trigano
BC: dimension A 1545mm, OHF: dimension C 2010mm, wheel connection 112x5, wheel brake type 2051A, offset (ET) 27-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5.
Price 1.395,00 EUR Incl. tax Excl. Shipping costs
Braked axle 1300kg EURO1 axle type B 1200-5, Sterckeman
AL-KO Braked axle 1300kg EURO1 axle type B 1200-5, Sterckeman
BC: dimension A 1545mm, OHF: dimension C 2025mm, wheel connection 130x4, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, taper-head wheel bolts M12x1.5.
Price 1.350,00 EUR Incl. tax Excl. Shipping costs
Page 3 of 14
