RUNNING WELL FOR YOU. BPW BERGISCHE AXLES

AL-KO Technology Paderborn GmbH specialises in the development and manufacture of complete running gear technology for car trailers and self-propelled vehicles. The location has developed from a labour-intensive wagon maker into an innovative, modern industrial company. Since 2017 the former BPW Fahrzeugtechnik has been part of the global technology company DexKo Global Inc., a worldwide market leader for trailer axles and chassis components in the lightweight segment. Read more...

Underpinning Your Progress.
The range of running gear for towable machinery, car and light truck trailers, caravans and cab & engine vehicles.



Clamping shell, single axle, vers. 2
BPW Clamping shell, single axle, vers. 2
drawbar tube square 70mm, axle profile square 80mm, for braked trailers.
Price 59,00 EUR Incl. tax Excl. Shipping costs
Clamping mount bolt on, for tube square 70mm
BPW Clamping mount bolt on, for tube square 70mm
for drawbar tube see diagram square 70mm, dimension H 50mm, dimension D 13mm, dimension A 160mm, dimension B 50mm, surface treatment hot-dip galvanised.
Price 55,60 EUR Incl. tax Excl. Shipping costs
Braked tandem axle unit 3000kg SWING axle type CB 2/1505, 4021491
BPW Braked tandem axle unit 3000kg SWING axle type CB 2/1505, 4021491
BC: dimension AM 1400mm, OHF: dimension FL 1940mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 1.950,00 EUR Incl. tax Excl. Shipping costs
Braked tandem axle unit 3000kg SWING axle type CB 2/1505, 4021489
BPW Braked tandem axle unit 3000kg SWING axle type CB 2/1505, 4021489
BC: dimension AM 1000mm, OHF: dimension FL 1570mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 1.940,00 EUR Incl. tax Excl. Shipping costs
Braked tandem axle unit 2700kg SWING axle type CB 2/1355, 49.25.379.166
BPW Braked tandem axle unit 2700kg SWING axle type CB 2/1355, 49.25.379.166
BC: dimension AM 1300mm, OHF: dimension FL 1750mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 1.515,00 EUR Incl. tax Excl. Shipping costs
Braked axle 3000kg RONDO axle type DS 3006, 45.46.373.224
BPW Braked axle 3000kg RONDO axle type DS 3006, 45.46.373.224
BC: dimension AM 1400mm, OHF: dimension SP 1900mm, wheel connection 205x6, wheel brake type S 3006-7 RASK, offset (ET) 0mm, swing arm position 13°, axle profile 114mm, ball-head wheel bolts M18x1.5.
Price 3.262,50 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1800kg RONDO axle type DB 1805, 45.32.368.632
BPW Braked tandem front axle 1800kg RONDO axle type DB 1805, 45.32.368.632
BC: dimension AM 1600mm, OHF: dimension FL 2100mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 35mm, swing arm position 13°, axle profile 92mm, ball-head wheel bolts M12x1.5.
Price 2.002,10 EUR Incl. tax Excl. Shipping costs
Braked tandem front axle 1350kg RONDO axle type DB 1354, 45.25.379.638
BPW Braked tandem front axle 1350kg RONDO axle type DB 1354, 45.25.379.638
BC: dimension AM 1900mm, OHF: dimension FL 2350mm, wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 70mm, taper-head wheel bolts M12x1.5.
Price 1.283,80 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg RONDO axle type DB 1055, 45.21.379.548
BPW Braked axle 1050kg RONDO axle type DB 1055, 45.21.379.548
BC: dimension AM 1900mm, OHF: dimension FL 2350mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 70mm, ball-head wheel bolts M12x1.5.
Price 1.268,80 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg RONDO axle type DB 1055, 45.21.379.538
BPW Braked axle 1050kg RONDO axle type DB 1055, 45.21.379.538
BC: dimension AM 1400mm, OHF: dimension FL 1850mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 70mm, ball-head wheel bolts M12x1.5.
Price 1.239,70 EUR Incl. tax Excl. Shipping costs
Braked axle 1050kg RONDO axle type DB 1054, 45.21.379.514
BPW Braked axle 1050kg RONDO axle type DB 1054, 45.21.379.514
BC: dimension AM 1200mm, OHF: dimension FL 1650mm, wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 70mm, taper-head wheel bolts M12x1.5.
Price 1.228,10 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1800kg axle type CB 1805, 4021148
BPW Braked axle SWING 1800kg axle type CB 1805, 4021148
BC: dimension AM 1400mm, OHF: dimension FL 1890mm, wheel connection 112x5, wheel brake type S 2504-7 RASK, offset (ET) 35mm, swing arm position 20°, axle profile 80/82mm, ball-head wheel bolts M12x1.5.
Price 915,00 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1350kg axle type CB 1355, 46.24.379.209, WÖRMANN
BPW Braked axle SWING 1350kg axle type CB 1355, 46.24.379.209, WÖRMANN
BC: dimension AM 1200mm, OHF: dimension FL 1625mm, wheel connection 112x5, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 0°, axle profile 80mm, ball-head wheel bolts M12x1.5.
Price 699,90 EUR Incl. tax Excl. Shipping costs
Braked axle SWING 1350kg axle type CB 1354, 46.25.379.720
BPW Braked axle SWING 1350kg axle type CB 1354, 46.25.379.720
BC: dimension AM 1000mm, OHF: dimension FL 1450mm, wheel connection 100x4, wheel brake type S 2005-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 80mm, taper-head wheel bolts M12x1.5.
Price 590,00 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 854, 46.16.382.017
BPW Braked axle 850kg SWING axle type CB 854, 46.16.382.017
BC: dimension AM 1350mm, OHF: dimension FL 1780mm, wheel connection 100x4, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, taper-head wheel bolts M12x1.5.
Price 438,90 EUR Incl. tax Excl. Shipping costs
Braked axle 850kg SWING axle type CB 854, 46.16.382.013
BPW Braked axle 850kg SWING axle type CB 854, 46.16.382.013
BC: dimension AM 1150mm, OHF: dimension FL 1580mm, wheel connection 100x4, wheel brake type S 1704-7 RASK, offset (ET) 30mm, swing arm position 20°, axle profile 64mm, taper-head wheel bolts M12x1.5.
Price 492,00 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZKV 20.1 B with overrun device AK 2008 height-adjustable, with drawbar section cranked 1300 to 2000kg, 47.36.471.021
BPW Drawbar installation ZKV 20.1 B with overrun device AK 2008 height-adjustable, with drawbar section cranked 1300 to 2000kg, 47.36.471.021
drawbar length L 1900mm, FD at max. 2000kg: 1526mm, drawbar section K round 101.6x10mm, spacer V 415mm, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 2.683,80 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 1.35-3 with overrun device ZAAQ1.35-3 / ZDG7-3 drawbar section cranked 750 to 1350kg, 48.25.381.062
BPW Drawbar installation ZAAR 1.35-3 with overrun device ZAAQ1.35-3 / ZDG7-3 drawbar section cranked 750 to 1350kg, 48.25.381.062
drawbar length L 3000mm, FD at max. 1350kg: 1210mm, drawbar section K square 70x5.0mm, measure HA 50mm, thread G M10, perm. nose load 100kg, with coupling head EM 150 R-B, for wheel brake S 1704-7 and S 2005-7.
Price 728,20 EUR Incl. tax Excl. Shipping costs
Drawbar installation ZAAR 1.6-1 with overrun device ZAAQ1.6 / ZDG7-3 drawbar section straight 800 to 1600kg, 48.29.181.043
BPW Drawbar installation ZAAR 1.6-1 with overrun device ZAAQ1.6 / ZDG7-3 drawbar section straight 800 to 1600kg, 48.29.181.043
drawbar length L 2500mm, FD at max. 1600kg: 1200mm, drawbar section K square 70x5.0mm, measure HA 50mm, thread G M10, perm. nose load 100kg, with coupling head EM 220 R-B, for wheel brake S 1704-7, S 2005-7 and S 2504-7.
Price 663,90 EUR Incl. tax Excl. Shipping costs
Overrun device square type ZAAQ 3.5-1, 2500 to 3500kg, 48.51.981.000
BPW Overrun device square type ZAAQ 3.5-1, 2500 to 3500kg, 48.51.981.000
connection dimension B 120mm, nose load 100kg, combined with BPW wheel brake S2005-7, S2504-7 and S3006-7 RASK, with coupling head EM 300 R-B.
Price 732,00 EUR Incl. tax Excl. Shipping costs
Drawbar eye NATO 76.0-02
BPW Drawbar eye NATO 76.0-02
dimension K 51.8mm, dimension S 76mm, dimension L 95mm, EG e1 0642 94/20 / ECE test code E1 55R-01 0642, nose load 150kg, perm. gross weight 3500kg, suitable for types ZAA 3.5-1, ZKV 25/35 and ZAV 3.5-1.
Price 455,20 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 2.0-3, 1250 to 2000kg, 48.36.581.094, 4014343, WM MEYER
BPW Overrun device V type ZAF 2.0-3, 1250 to 2000kg, 48.36.581.094, 4014343, WM MEYER
connection 166mm, nose load 150kg, drawbar installation version top + bottom, combined with AL-KO wheel brake 2051 and 2361, with coupling head EM 220 R-A.
Price 385,00 EUR Incl. tax Excl. Shipping costs
Overrun device V type ZAF 2.0-3, 1250 to 2000kg, 48.36.581.200
BPW Overrun device V type ZAF 2.0-3, 1250 to 2000kg, 48.36.581.200
connection 166mm, nose load 150kg, drawbar installation version top + bottom, combined with BPW wheel brake S1704-7, S2005-7 and S2504-7 RASK, with coupling head EM 220 R-A.
Price 346,70 EUR Incl. tax Excl. Shipping costs
Towbar connection ZOV 1.2-1.1 B height-adjustable with drawbar section up to 1200kg, 47.23.403.010
BPW Towbar connection ZOV 1.2-1.1 B height-adjustable with drawbar section up to 1200kg, 47.23.403.010
drawbar length L 1070mm, drawbar section K 82.5mm, with DIN drawbar eye dimension A 523mm, height B 0-225mm, intermediate piece V 300mm, perm. nose load 100kg.
Price 957,80 EUR Incl. tax Excl. Shipping costs
