Home / Braked tandem axle unit 2700kg EURO1 axle type 2xB 1200-6 - LINDDANA
BC: dimension A 960/1040mm, OHF: dimension C 1600mm, wheel connection 112x5, wheel brake type 2051 vers. A, offset (ET) 26-30mm, swing arm position 25°, axle profile 97mm, ball-head wheel bolts M12x1.5. Read more...
Part no. 1426072 (1529549+1529550)
Axle type: 2xB 1200-6
Axle load tandem: 2700kg
Axle dimensions
BC dimension A front axle: 960mm
BC dimension A rear axle: 1040mm
OHF dimension C: 1600mm
Axle beam Ø: 97mm
Rims and tyres
Wheel brake: 2051 vers. A
Wheel connection: 112x5
Wheel bolt: M12x1.5 ball-head
Offset (ET) from to: 26-30mm
Recommended rims: 5.5Jx14 (not included in scope of delivery)
Recommended tyres: 185R14 (not included in scope of delivery)
Original operating instructions
SCOPE OF DELIVERY
Tandem axle unit braked
Tandem axle trailer adapter bracket welded on
Tandem plug-on adapter bracket loose
Tandem compensation loose
Bowden cables loose
Wheel bolts loose
SURFACE TREATMENT
Axle profile hot-dip galvanised
Wheel brake galvanised
ACCESSORIES (not included in scope of delivery)
Shock absorber
Other designs available on request.
