BC: dimension A 410mm, OHF: dimension C 646,5mm, wheel connection 112x5, wheel brake type 2361, offset (ET) 27-40mm, swing arm position 0°, axle profile 95mm, ball-head wheel bolts M12x1.5. Read more...
Part no. 46.32.368.326 + 327
| Braked half axles |
| Axle load per pair |
1800kg |
| Type | CBST 1805 |
| Wheel brake |
S2504-7 RASK |
| Wheel connection |
112x5 |
| BC: dimension A | 410mm |
| OHF: dimension C | 646,5mm |
| Offset: ET |
27-40mm |
SCOPE OF DELIVERY
Half axles
Adapter bracket single axle loose
Single axle trailer compensation profile loose
Bowden cables loose
Wheel bolts loose
SURFACE TREATMENT
Hot-dip galvanised axle profile
